Introduction:
The EDC16 system is used in cars like the Seat Leon, golf 5 and other cars that are produced in the same
period. The system looks a lot like the EDC15 system, but the EDC16 system is based on Torque (Nm)
instead of Injected Quantity. There are a few more differences that are explained in this document. For all
examples in this document I used the Seat Leon 105hp file
5/28/2018 EDC16 Tuning Guide
4/10
5/28/2018 EDC16 Tuning Guide
5/10
Fuel related maps
1. Drivers wish Maps:
General:
This map shows the required torque based on the RPM and the Throttle position. The output of this map is
Torque in Nm. There may be more drivers wish maps, in the file I used for this guide there were 8 drivers
wish maps.
Picture 1.1: 3D view of the drivers wish map.
Factors & offsets:
Map properties
Description: Torque
Unit: Nm
Name: Drivers wish
Start address: 1C2F96
Column x rows: 8x16
Values: 16Bit(HiLo)
Factor: 0.1
Offset: 0
X-Axis
Description: Throttle position
Unit: %
Start address: 1C2F86
Values: 16Bit(HiLo)Factor: 0.01
Offset: 0
Y-Axis
Description: Rpm
Unit: 1/min
Start address: 1C2F66
Values: 16Bit(HiLo)
Factor: 1
Offset: 0
5/28/2018 EDC16 Tuning Guide
6/10
2. Torque limiter:
General:
This map limits the torque of the engine based on RPM and atmospheric pressure. The output of this map
is also Torque in Nm.
Picture 2.1: 3D view of the Torque limiter
Factors & offsets:
Map properties
Description: Torque
Unit: Nm
Name: Torque limiter
Start address: 1D43C2Column x rows: 21x3
Values: 16Bit(HiLo)
Factor: 0.1
Offset: 0
X-Axis
Description: Rpm
Unit: 1/min
Start address: 1D4398
Values: 16Bit(HiLo)
Factor: 1Offset: 0
Y-Axis
Description: Atmospheric pressure
Unit: Hpa
Start address: 1D4392
Values: 16Bit(HiLo)
Factor: 1
Offset: 0
5/28/2018 EDC16 Tuning Guide
7/10
3. Nm to IQ conversion map:
General:
This map converts the requested Torque in Nm into IQ (injected quantity).
Picture 3.1: 3D view of the NM to IQ conversion map.
Factors & offsets:
Map properties
Description: IQ
Unit: mg/stroke
Name: Nm to IQ converion map
Start address: 1D6F9A
Column x rows: 16x15
Values: 16Bit(HiLo)
Factor: 0.1
Offset: 0
X-Axis
Description: Rpm
Unit: 1/min
Start address: 1D6F7A
Values: 16Bit(HiLo)
Factor: 1
Offset: 0
Y-Axis
Description: Torque
Unit: Nm
Start address: 1D6F5C
Values: 16Bit(HiLo)
Factor: 0.1
Offset: 0
5/28/2018 EDC16 Tuning Guide
8/10
4. Turbo map:
General:
This map set the required boost depending on the requested torque and current rpm. There might be more
than one boost map. In this file there are 2 boost maps.
Picture 4.1: 3D view of the Boost map.
Factors & offsets:
Map properties
Description: Boost
Unit: mBar
Name: Boost map
Start address: 1EAD92
Column x rows: 10x16(the other map in this file is 10x15)
Values: 16Bit(HiLo)Factor: 1
Offset: 0
X-Axis
Description: Torque
Unit: Nm
Start address: 1EAD7E
Values: 16Bit(HiLo)
Factor: 0.1
Offset: 0
Y-Axis
Description: Rpm
Unit: 1/min
Start address: 1EAD5E
Values: 16Bit(HiLo)
Factor: 1
Offset: 0
5/28/2018 EDC16 Tuning Guide
9/10
5. Turbo limiter map:
General:
This map limits the required boost depending on the atmospheric pressure and the current rpm.
Picture 5.1: 3D view of the Boost limiter map.
Factors & offsets:
Map properties
Description: Boost
Unit: mBar
Name: Boost limiter map
Start address: 1EAF00
Column x rows: 10x11
Values: 16Bit(HiLo)
Factor: 1
Offset: 0
X-Axis
Description: Atmospheric pressure
Unit: Hpa
Start address: 1EAEEC
Values: 16Bit(HiLo)
Factor: 1
Offset: 0
Y-Axis
Description: Rpm
Unit: 1/min
Start address: 1EAED6
Values: 16Bit(HiLo)
Factor: 1
Offset: 0
5/28/2018 EDC16 Tuning Guide
10/10
1EAD44 - 2050mBar need mode..??????
1EB04A - Single Boost limiter?????????
next map not need mod????
Conclusion:
Let's start an EDC17 tuning guide for a VAG car. The original file is from a 2.0L TDi 143hp Common Rail. Don't have much time to post images, so I will leave adresses, factors and offsets for someone with some more time make a pdf. Driver's Wish: 1B1D20, 1B1E54, 1B1F88, 1B20BC, 1B21F0 and 1B2324 Map Properties: Torque / Nm Factor: 0,1 Offset: 0.
